Description
A cone crusher is generally used as a secondary crusher in a crushing circuit. Pre-crushed product is fed through the top of the cone crusher and flows over the mantle. The vertical cone crusher drive shaft rotates the mantle eccentrically below the concave, or bowl liner, squeezing the product and crushing it between the mantle and concave. Cone crushers are usually run on belt drives driven by an electric motor or diesel engine. Cone crushers are used extensively throughout the aggregate and mineral processing industry.
Product Model
| Model | Dia. mm (inch) | Cavity | Closing Side (mm) | Open Side (mm) | Outlet Setting (mm) | Shaft Speed (r/min) | Power (kw) | Capacity (t/h) | Weight (t) | Dimension (mm) |
| CSB75 | 900 (3') | Fine | 83 | 102 | 9-22 | 580 | 75 | 45-91 | 15 | 2821x1880x2164 |
| Coarse | 159 | 175 | 13-38 | 59-163 | ||||||
| CSB110 | 1200 (4') | Fine | 127 | 131 | 9-31 | 485 | 110 | 63-188 | 20 | 2821x1974x2651 |
| Medium | 156 | 156 | 13-38 | 100-200 | ||||||
| Coarse | 178 | 191 | 19-51 | 141-308 | ||||||
| CSB160 | 1295 (4 1/4') | Fine | 109 | 137 | 13-31 | 485 | 160 | 109-181 | 27 | 2800x2342x2668 |
| Medium | 188 | 210 | 16-31 | 132-253 | ||||||
| Coarse | 216 | 241 | 19-51 | 172-349 | ||||||
| CSB240 | 1650 (5 1/2') | Fine | 188 | 209 | 16-38 | 485 | 240 | 181-327 | 55 | 3911x2870x3771 |
| Medium | 213 | 241 | 22-51 | 258-417 | ||||||
| Coarse | 241 | 268 | 25-64 | 299-635 | ||||||
| CSB315 | 2134 (7') | Fine | 253 | 278 | 19-38 | 435 | 315 | 381-726 | 110 | 4613x3251x4732 |
| Medium | 303 | 334 | 25-51 | 608-998 | ||||||
| Coarse | 334 | 369 | 31-64 | 789-1270 |
