Lignite Coal Dryer - Henan Jiechang Machinery

Description

Overview
Lignite Coal Dryer, also known as Lignite Rotary Dryer, Brown Coal Dryer, Lignite Dryer or Coal Ash Dryer, is suitable for granular materials and can also be partially put into dry adhesive materials, pasty materials or high water content materials. Lignite Coal Dryer is widely for drying materials in the field of cement, mining, building materials, chemical, food, fertilizer production industry, etc.

Principle
Raw materials are sent into feeder by conveyor belt, and the coal ash is sent into drying roller through the feeder. With the ruffle of uniformly distributed board device in drying roller, the coal ash is evenly contacted with hot air to transfer heat and perfect drying. The dried coal ash is discharged into finished products via shedder in the end of the roller. The dried products are discharged by the belt discharging machine, and the drying process is finished.

Feature
1. Minimize drying cost but maximize safety of drying production;
2. High quality of drying finished product,
3. Heavy drying strength and high drying efficiency.

Product Model

Model (mm)	Obliquity(%)	Revolution Speed (r/min)	Inlet Air Temperature (°C)	Power (kw)	Capacity(t/h)	Weight (t)
Ф600x6000	3-5	3-8	≤700	3	0.5-1.5	2.9
Ф800x8000	3-5	3-8	≤700	4	0.8-2.0	3.5
Ф800x10000	3-5	3-8	≤700	4	0.8-2.5	4.5
Ф1000x10000	3-5	3-8	≤700	5.5	2-5	5.6
Ф1200x12000	3-5	3-8	≤700	11	4-10	14.8
Ф1500x12000	3-5	2-6	≤800	18.5	8-15	17.8
Ф1800x18000	3-5	2-6	≤800	22	10-23	31
Ф2000x18000	3-5	1.5-6	≤800	30	15-26	43
Ф2200x18000	3-5	1.5-6	≤800	37	20-32	52
Ф2200x20000	3-5	1.5-6	≤800	30	12-20	56
Ф2400x20000	3-5	1.5-5	≤800	55	25-38	60
Ф2800x20000	3-5	1.5-5	≤800	75	35-50	72
Ф3000x25000	3-5	1.5-5	≤800	90	40-65	104.9
Ф3200x25000	3-5	1.5-6	≤800	132	75-105	166
Ф3600x25000	3-5	1.5-6	≤800	155	95-160	188
