Sand Washer

Ask for quote


Sand washing machine, also called sand washer machine and silica sand washing machine, is a kind of washing equipment for artificial and natural sand. It is one of the major equipment of sand production line. The main task of this equipment in sand production line is to clean the crushed sand materials.
Simply put, Sand washing machine is used to remove the dust and stone powder in the sand produced by sand making machine, it also can do sand-selecting work or the similar process. The machine aims at improve the quality and grade of the sand.

When the sand washing machine or sand washing plant works, the power plant drives the impeller to slowly rotate after slowing down through the V-shaped belt, reducer and gear, and sand and stone materials go into the washing chute from the material cabin, and roll driven by the impeller and grind with each other to remove the impurities covering the surface of the sand and stone materials, and at the same time break the moisture layer coated on the sand particles for the purpose of dehydration. In the meantime, add water in it to form a strong water flow to timely wash away the impurities and foreign matters with small proportion and discharge them from the overflow port to complete the washing process.

1. Rational structure
2. Minimal loss of fine sand and powder,
3. Large capacity, small power consumption;
4. Long life, easy maintenance;
5. Energy saving.

Product Model

Specification XS2200 XS2600 XS2900 XS3500
Wheel bucket diameter
2200 2600 2900 3500
Rotation Speed
1-2 1-2 0.8-1.5 0.8-1.2
Processing capacity (t/h) 15-30 20-50 50-100 120-200
Motor power
4 5.5 7.5 11
Total weight
4300 5600 8100 9900
Dimensions (LxWxH)
3150x1910x2280 3520x2390x2690 3820x2640x3200 4420x2930x3800
